High Temperature SiC Ceramic Rod Silicon Carbide Ceramic Insulator Shaft
$25.00
Product Description
Product Name | Wear resistance SiC ceramic insulating substrate |
Material | SIC |
Key words | Silicon Carbide Ceramic rod |
Advantage | High temperature resistance |
SIC rod introduction
Silicon carbide Ceramic is one kind of technical ceramic materials which has very good performance in high temperature, its mechanical strength can be kept up to 1600??. Its hardness and wear resistance performance ranks high among all technical ceramic materials.
SIC ceramic rod
2.Moderate thermal conductivity
3. Low coefficient of thermal expansion
4. Moderately high elastic modulus
Technical date of silicon carbide(SIC) | ||||||
Item | SSIC | RBSIC/SISIC | RSIC | |||
Max temperature of application | 1600?? | 1300?? | 1650?? | |||
Density | ??3.10g/cm3 | ??3.03g/cm3 | ??2.6g/cm3 | |||
Open Porosity | ??0.1% | ??0.1% | 15.00% | |||
Thermal Conductivity | 74W/mk | 45W/mk | 24W/mk | |||
Hardness | 9.2~9.4HRA | 9.1~9.3HRA | ||||
Acid Alkaline-proof | Excellent | Excellent | Excellent | |||
Coefficient of thermal expansion | 4.0 K -1 x10 -6 | 4.0 K -1 x10 -6 | 4.8 K -1 x10 -6 | |||
Bending strength | ≥400Mpa | ≥350Mpa | 90~100Mpa(20?棩 | |||
100~120Mpa(1100?棩 | ||||||
Modulus of elasticity | 400Gpa | 350Gpa | 240Gpa | |||
