Pagoda Head Porous Ceramic Tube Soil Tensiometer Seepage Ceramic Tube Plant Moisture Monitor Clay Head

$10.00

100 in stock


Product Description

Porous ceramic tube
The soil tensiometer is composed of pressure gauge, acrylic tube and ceramic head. After the acrylic tube is filled with water,
the ceramic head is wet and prevents outside air from entering the ceramic head.


The ceramic head is the sensing part of the instrument and has many tiny pores. After the ceramic head is wetted by water, a water
film is formed in the pores. When the water-filled and sealed soil hygrometer is inserted into the unsaturated soil, the water
film will be connected with the soil water, so that the water inside the instrument will generate negative pressure. At this time,
the value displayed by the pressure gauge is the measured soil. soil water potential.

The advantages of the ceramic head produced by our company:
1. Customizable porosity and size


The advantages of the ceramic head produced by our company:
2. Environmentally friendly, non-toxic, long life


The advantages of the ceramic head produced by our company:
3. The liquid absorption rate is stable

The advantages of the ceramic head produced by our company:
4. Acid and alkali corrosion resistance, suitable for various soil environments
5. Customized matching plastic accessories

??Ŀ
Item
????ͷ/?????
Infiltration Cup
ֲ????ˮ??
Plant Water Absorbing Wick
?缫ɰо
Electrode Wick
?մ?о??
Ceramic Wick
??޹?մ?
Scented Ceramic
??ɫ??????
White alumina
̼????
Silicon Carbide
?ܶȣ?g/cm³??Density
1.6-2.0
0.8-1.2
1.8-2.2
0.8-1.2
1.6-2.0
1.7-2.0
???ſ???(%)
Open Porosity Rate
30-40
50-60
20-30
40-60
30-45
35-40
??????(%)
Porosity Rate
40-50
60-75
25-40
60-75
40-50
40-45
??ˮ??(%)
Water Absorption
25-40
40-70
10-28
40-70
25-40
25-35
?׾???μm??
Pore Size
1-5
1-3
1-3
1-3
1-5
1-10

Company Profile

Based on quartz and ceramics, after more than 20 years development, Highborn Group has grown up to a modern enterprise in research, manufacture, processing and sales. We are mainly supplying quartz glass, cuvette, precise ceramics, porous ceramics,thick film resistor, ozone generator, metal fiber felt and we have been offering our products and services to our clients from more than 103 countries or regions.
Highborn Group is paying great attention to the product quality and technology research all the time. We have passed ROHS, CE,MSDS tests and also the ISO9001 authentication. We have 8 registered trademark and 25 patents. Also in 2020, we won the title of China High-tech Enterprise and Jiangsu Private Science and Technology Enterprises.

We can offer not only qualified products, we can also supplying quality service including design, development, export and after sales. With our professional skills, advanced technology and quality material, we can design and develop new products or new applications according to the clients’ expectation. We have custom-made new products and promoted the specifications for more than
1000 clients, and we have gotten good reputation from our clients.

Certifications

Our Honour

Our Patent

Our Certification

Product packaging

Shipping
1. By Air (China Post Air Mail, ePacket, DHL, UPS, TNT, FEDEX) 2. By Sea (From Qingdao,Shanghai)
Both air and sea shippment is available, it's depend on your request.
Deliver Time:
1. Sample order: 3-7days after receipt of payment.
2. Bulk order: 7-15 days after receipt of payment

Our Service


1, OEM service.
2, Produce per customers' request such as design & package & printing logo.
3, Special package for fragile products to make sure no broken in transportation.
4, The Trade Assurance Service is ready for you and our guarantee account is USD40000.
5, Golden supplier.
6, 20% compain feedback.
7, 100% good reputation.

FAQ

1??What products and service can you offer us?
Answer: With the development more than 20 years, now we have 6 business division and we are supplying Quartz Glass (Tube, Rod,Plate and customized parts), optical glass and cuvette, and also various precise ceramics, porous ceramics and refractory ceramics. We have the full processing line for ceramic thick film resistors, far infrared ceramic glass heating panel, quartz tube/ceramic plate ozone generator and porous metal fiber felt. For all the products, we can design and customize according to the
clients’ demand.

2: Before mass order, can you offer samples? How will you charge for them?
Answer: We are willing to offer samples to lower your purchasing risk. Generally, if from inventory, we can deliver out within 3days, however if need processing, we can deliver out within 15days. For some difficult items, the delivery time will be decided by its grade of difficulty. For some low value items, we can offer free sample, however we would like you to afford the freight cost. For customized products, we need to charge the developing cost.

3: What test report or certificate can you offer? What achievements have you made in research and development?
Answer: Till the end of 2021, we have passed many ROHS, CE, MSDS tests and also the ISO9001 authentication. We have 8 registered trademark and 25 patents. Also we won the title of China High-tech Enterprise and Jiangsu Private Science and Technology Enterprises.

4: Do you have any agent in our area? Can you export your products directly?
Answer: Till the end of 2021, we haven’t authorized any company or person as our regional agent. From 2008, we have the export qualification and professional export team, and till the end of 2021, we have exporting our products to more than 103 countries and regions, and our clients can contact us and purchase our products or service directly.

5: If the quality can not meet the requirement or any loss during the freight, how should we do?
Answer: We have strict QC test and professional QC team. We are always offering qualified products. If anything goes wrong, the quality can not meet requirement on the contract, we will reproduce the qualified products or refund the payment. We have the professional packing team and will pack the product in safe package for long distance delivery. If any loss during the freight, we hope you can assistant us to claim from the logistics company and we will arrange the replacement accordingly.
